Basic standard:

API 602, BS5352, ASME B16.34

Flange connection dimesion:

ASME B16.5

Butt welding connection dimension(BW):

ASME B16.25

Socket welding connetiong dimension(SW):

ASME B16.11

Threaded end dimension(NPT):

ASME B1.20.1

Face-to-face dimension:

ASME B16.10, MTD for SW end , NPT end and BW end

Pressure-Temperature rating:

ASME B16.34

Test:

API 598

Size:

1/2’’-2’’

Rating:

ANSI 150lbs ~ 1500lbs

Body Materials:

Forged carbon steel, Forged stainless steel, Forged alloy steel, Forged duplex.

Trim:

Per API 600

Operation:

Handwheel
